Engine

Cylinder Head Nuts: 14.5 - 18.1 (ft·lbs)

Cam Chain Guide Roller Bolt: 6.5 - 8.7 (ft·lbs)

Clutch / Oil Filter Castle Nut: 27.4 - 32.5 (ft·lbs)

A.C. Generator Rotor Bolt: 18.8 - 23.2 (ft·lbs)

A.C. Generator Stator Bolt: 5.8 - 8.7 (ft·lbs)

Camshaft Sprocket Bolt: 6.5 - 8.7 (ft·lbs)

Spark Advancer Bolt: 5.8 - 8.7 (ft·lbs)

Shift Drum Bolt: 5.8 - 8.7 (ft·lbs)

Frame

Handlebar Setting Bolts: 5.8 - 8.7 (ft·lbs)

Steering Stem Nut: 43.4 - 50.7 (ft·lbs)

Front Fork Bolt: 25.3 - 32.6 (ft·lbs)

Steering Bottom Bridge Bolt: 13.0 - 28.1 (ft·lbs)

Swingarm Pivot: 29.0 - 43.4 (ft·lbs)

Rear Shock Absorber Upper Nut: 18.1 - 25.3 (ft·lbs)

Rear Shock Absorber Lower Nut: 18.1 - 25.3 (ft·lbs)

Front Axle Nut: 25.3 - 36.2 (ft·lbs)

Rear Axle Nut: 25.3 - 36.2 (ft·lbs)

Rear Axle Sleeve Nut: 25.3 - 36.2 (ft·lbs)

Driven Sprocket Bolt: 13.0 - 18.1 (ft·lbs)

Rear Brake Stop Arm Bolt: 13.0 - 18.1 (ft·lbs)

Engine Hanger Bolt: 21.7 - 29.0 (ft·lbs)

Step Bar Bolt: 13.0 - 18.1 (ft·lbs)

All Other Standard Bolts and Screws

Bolt and Nut

5mm: 3.3 - 4.3 (ft·lbs)

6mm: 5.8 - 8.7 (ft·lbs)

8mm: 13.0 - 18.1 (ft·lbs)

10mm: 21.7 - 29.0 (ft·lbs)

12mm: 36.2 - 43.4 (ft·lbs)

Screw

5mm: 2.5 - 3.6 (ft·lbs)

6mm: 5.1 - 8.0 (ft·lbs)

Flange Bolt and Nut

6mm: 7.2 - 10.1 (ft·lbs)

8mm: 17.4 - 21.7 (ft·lbs)

10mm: 21.7 - 29.0 (ft·lbs)
